BRAINBOXES ES-257 Ethernet to 2 x RS232 Serial Adapter

Available on backorder

Next day delivery Order by 4pm Monday - Friday

Free delivery on orders over £50 (terms apply)

£167.76 incl. TAX
£139.80 excl. TAX

BRAINBOXES ES-257 Ethernet to 2 x RS232 Serial Adapter

Product Code: 7315R-2

Product Features

2 Port RS232 Ethernet to Serial Adapter
2 Port RS-232
Ethernet to Serial Device Server
Data rate from 110 to 1,000,000 baud (1 MegaBaud)
£167.76 incl. TAX
£139.80 excl. TAX

Available on backorder

Next day delivery Order by 4pm Monday - Friday

Free delivery on orders over £50 (terms apply)

£167.76 incl. TAX
£139.80 excl. TAX

Available On Backorder

1+
£167.76 incl. TAX
£139.80 excl. TAX
3+
£161.76 incl. TAX
£134.80 excl. TAX

Product Quantity Price per Unit
1+ £139.80
3+ £134.80
Enquire about this product
(8.30am-6pm Mon-Fri)
Description
Key Features
Specifications

Product Description

Ethernet to Serial device server providing access to two RS232 serial ports. Data transfer rates up to 1,000,000 baud (1 MegaBaud), coupled with 1Mbit/s line drivers deliver uncompromising performance. Baud rates can be standard values such as 9,600, 115,200, 230,000, 921,600 or user definable non standard values.Our ES range provides simple instant networked serial ports. A web interface allows secure configuration and control of the serial ports over a local network or the internet using any browser.For Windows our in-house designed (32 bit and 64 bit) driver gives you local COM ports, retaining existing software applications and allowing you to connect across your network to remote devices just as if they were attached locally.Serial Port Tunnelling (individually configurable) allows serial cable replacement over any distance, no software required. You can access the device via TCP/IP sockets from any networked device like an Android tablet, PC or phone. On Windows OS TCP/IP sockets are handled by the Winsock API, this will differ on other OSs.

Product Features

2 Port RS232 Ethernet to Serial Adapter
2 Port RS-232
Ethernet to Serial Device Server
Data rate from 110 to 1,000,000 baud (1 MegaBaud)
Install Virtual Com ports or use the Software APIs for Visual Basic, C# and more
Serial Port Tunnelling allows serial cable replacement over any distance, no software required
Power supply included (power input 5-30V DC)

Specifications

Weight 0.50 kg
Brand BRAINBOXES
Manufacturer Product Code ES-257
Here to help

Call, e-mail or connect via LiveChat and you will always be helped by an experienced member of the team.

Chat with us

8:30am–6pm working day

Live Chat
Speak to your account manager

Speak to your dedicated account manager

Description

Product Description

Ethernet to Serial device server providing access to two RS232 serial ports. Data transfer rates up to 1,000,000 baud (1 MegaBaud), coupled with 1Mbit/s line drivers deliver uncompromising performance. Baud rates can be standard values such as 9,600, 115,200, 230,000, 921,600 or user definable non standard values.Our ES range provides simple instant networked serial ports. A web interface allows secure configuration and control of the serial ports over a local network or the internet using any browser.For Windows our in-house designed (32 bit and 64 bit) driver gives you local COM ports, retaining existing software applications and allowing you to connect across your network to remote devices just as if they were attached locally.Serial Port Tunnelling (individually configurable) allows serial cable replacement over any distance, no software required. You can access the device via TCP/IP sockets from any networked device like an Android tablet, PC or phone. On Windows OS TCP/IP sockets are handled by the Winsock API, this will differ on other OSs.

Key Features

Product Features

2 Port RS232 Ethernet to Serial Adapter
2 Port RS-232
Ethernet to Serial Device Server
Data rate from 110 to 1,000,000 baud (1 MegaBaud)
Install Virtual Com ports or use the Software APIs for Visual Basic, C# and more
Serial Port Tunnelling allows serial cable replacement over any distance, no software required
Power supply included (power input 5-30V DC)
Specifications

Specifications

Weight 0.50 kg
Brand BRAINBOXES
Manufacturer Product Code ES-257
